FFD-100H - Si PIN - 2.5mm- TO-5, PC, Ultrafast
The FFD-100H is a Large-Area Silicon PIN Photodiode with a 2.5 mm active diameter in a hermetically-sealed TO-5 package. This photodiode produces high responsivity from 400 nm to 1150 nm with a peak responsivity at 920 nm. It features an ultra-fast rise and fall time, low NEP and a low operating voltage.
Features & Benefits:
- Large area Silicon (Si) PIN photodiode
- TO-5 hermetically-sealed package
- 2.5 mm active diameter chipĀ
- Ultra -fast rise and fall time
- Isolated photodiode chip
Applications:
- Laser detection systems
- Laser power control systems
- Fast pulse detection in semiconductor inspection systems
- Instrumentation
- High speed switching
Breakdown Voltage: 150 V
Capacitance: 8.5 pF
Dark Current: < 25 nA
Noise Current: < 90 fA/āHz
Package: TO-5
Peak Wavelength: 850 nm
Responsivity: 0.6 A/W
Rise/Fall Time: 1 ns
Spectral range:Ā 400 nm -1150 nm
Breakdown Voltage: 150 V
Capacitance: 8.5 pF
Dark Current: < 25 nA
Noise Current: < 90 fA/āHz
Package: TO-5
Peak Wavelength: 850 nm
Responsivity: 0.6 A/W
Rise/Fall Time: 1 ns
Spectral range:Ā 400 nm -1150 nm
