Mounted Symmetric-Convex Lenses, Uncoated

Our LINOS® mounted symmetric-convex singlets are available in various focal lengths and diameters to meet a range of application needs. We use premium materials from trusted manufacturers and maintain strict tolerances to ensure exceptional quality. These lenses are offered in a black anodized, engraved aluminum mount.

Contact Us Buy Now at Digikey

Made from N-BK7 glass for optimal clarity, our mounted symmetric-convex lenses integrate seamlessly with LINOS Microbench and Nanobench systems. Tight focal-length tolerances ensure reliable optical performance, and the dual equal radii of curvature provide precise beam convergence. The uncoated design supports a broad wavelength range, making these singlets adaptable for many optical configurations.

ZEMAX files enable fast, accurate optical design and simulation. For customized specifications or high-volume production, contact us for a quotation tailored to your technical requirements.

BIKONVEX-SYM-Ai_4868

Note: f = focal length (object side), f' = focal length (image side) , s = object distance, s' = back focal length, Ø = lens diameter, dm = center thickness, dr = edge thickness, h = primary vertex (h=dm-dr-h'), F, F' = focal points, H, H' = principal points; Tolerances: focal length f: ±2% image distance s': ±2%

Symmetric-Convex Singlet lenses graphic

Note: Dmech: outer mount, DCA: clear aperture, Doptical: optical size, RR: retaining ring

Product Biconvex lens; N-BaK 4; D=6; F=5; mounted Biconvex lens; N-BK 7; D=22.4; F=40; mounted Biconvex lens; N-BaK 4; D=8; F=7; mounted Biconvex lens; N-BaK 4; D=10; F=10; mounted Biconvex lens; N-BK 7; D=12.5; F=12.5; mounted Biconvex lens; N-BK 7; D=12.7; F=15; mounted Biconvex lens; N-BK 7; D=12.7; F=20; mounted Biconvex lens; N-BK 7; D=12.7; F=30; mounted Biconvex lens; N-BK 7; D=12.7; F=50; mounted Biconvex lens; N-BK 7; D=12.7; F=150; mounted Biconvex lens; N-BK 7; D=18; F=16; mounted Biconvex lens; N-BK 7; D=22.4; F=20; mounted Biconvex lens; N-BK 7; D=22.4; F=25; mounted Biconvex lens; N-BK 7; D=22.4; F=30; mounted Biconvex lens; N-BK 7; D=22.4; F=50; mounted Biconvex lens; N-BK 7; D=22.4; F=60; mounted Biconvex lens; N-BK 7; D=22.4; F=80; mounted Biconvex lens; N-BK 7; D=22.4; F=100; mounted Biconvex lens; N-BK 7; D=22.4; F=200; mounted Biconvex lens; N-BK 7; D=22.4; F=150; mounted Biconvex lens; N-BK 7; D=25.4; F=30; mounted Biconvex lens; N-BK 7; D=25.4; F=50; mounted Biconvex lens; N-BK 7; D=25.4; F=80; mounted Biconvex lens; N-BK 7; D=25.4; F=100; mounted Biconvex lens; N-BK 7; D=25.4; F=150; mounted Biconvex lens; N-SK2; D=31.5; F=30; mounted Biconvex lens; N-BK 7; D=31.5; F=40; mounted Biconvex lens; N-BK 7; D=31.5; F=50; mounted Biconvexl lens; N-BK 7; D=31.5; F=70; mounted Biconvex lens; N-BK 7; D=31.5; F=130; mounted
Shape Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular
Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted
Mount Nanobench Microbench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench
Focal Length (+/-) 5.0 mm 40.0 mm 7.0 mm 10.0 mm 12.5 mm 15.0 mm 20.0 mm 30.0 mm 50.0 mm 150.0 mm 16.0 mm 20.0 mm 25.0 mm 30.0 mm 50.0 mm 60.0 mm 80.0 mm 100.0 mm 200.0 mm 150.0 mm 30.0 mm 50.0 mm 80.0 mm 100.0 mm 150.0 mm 30.0 mm 40.0 mm 50.0 mm 70.0 mm 130.0 mm
Optic Substrate N-BAK4 N-BK7 N-BAK4 N-BAK4 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-SK2 N-BK7 N-BK7 N-BK7 N-BK7
Optic Size Ø 6.0 mm Ø 22.4 mm Ø 8.0 mm Ø 10.0 mm Ø 12.5 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 18.0 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm
Optic Center Thickness 2.9 mm 5.0 mm 3.4 mm 3.5 mm 4.5 mm 4.0 mm 3.0 mm 3.0 mm 3.0 mm 3.0 mm 7.0 mm 8.8 mm 7.0 mm 6.3 mm 4.5 mm 4.0 mm 3.5 mm 3.5 mm 3.0 mm 3.0 mm 7.0 mm 7.0 mm 7.0 mm 7.0 mm 7.0 mm 9.5 mm 8.3 mm 7.0 mm 5.5 mm 4.0 mm
Length 8.0 mm 10.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 12.0 mm 12.0 mm 12.0 mm 12.0 mm 12.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm
Radius of Curvature 1 5.085 mm 41.867 mm 7.499 mm 10.669 mm 11.971 mm 14.749 mm 20.097 mm 30.287 mm 51.08 mm 153.99 mm 15.179 mm 19.248 mm 24.406 mm 30.069 mm 52.33 mm 62.643 mm 83.536 mm 104.41 mm 209.83 mm 156.22 mm 30.069 mm 51.08 mm 81.166 mm 102.92 mm 153.99 mm 34.721 mm 41.867 mm 52.33 mm 72.862 mm 134.325 mm
Radius of Curvature 2 -5.085 mm -41.867 mm -7.499 mm -10.669 mm -11.971 mm -14.749 mm -20.097 mm -30.287 mm -51.08 mm -153.99 mm -15.179 mm -19.248 mm -24.406 mm -30.069 mm -52.33 mm -62.643 mm -83.536 mm -104.41 mm -209.83 mm -156.22 mm -30.069 mm -51.08 mm -81.166 mm -102.92 mm -153.99 mm -34.721 mm -41.867 mm -52.33 mm -72.862 mm -134.325 mm
Tolerance thickness ± 0.1 mm ± 0.2 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm
Optic Edge Thickness 0.9 mm 2.0 mm 1.1 mm 1.0 mm 1.0 mm 1.1 mm 0.9 mm 1.6 mm 2.2 mm 2.7 mm 1.1 mm 1.6 mm 1.6 mm 2.0 mm 2.1 mm 2.0 mm 2.0 mm 2.3 mm 2.4 mm 2.2 mm 1.4 mm 3.8 mm 5.0 mm 5.4 mm 6.0 mm 2.0 mm 2.1 mm 2.1 mm 2.1 mm 2.2 mm
Optic Centering Accuracy (min,sec) 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 '
Tolerance of optic size - 0.075 mm - 0.13 mm - 0.09 mm - 0.09 mm - 0.11 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.11 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.07 mm - 0.07 mm - 0.07 mm - 0.07 mm - 0.07 mm
f' at X nm 4.97 mm
5.0 mm
5.08 mm 		41.2 mm
41.48 mm
42.16 mm 		7.14 mm
7.21 mm
7.33 mm 		9.93 mm
10.01 mm
10.17 mm 		12.33 mm
12.41 mm
12.61 mm 		14.91 mm
15.01 mm
15.25 mm 		19.88 mm
20.02 mm
20.34 mm 		29.7 mm
29.9 mm
30.4 mm 		49.74 mm
50.08 mm
50.91 mm 		148.9 mm
150.0 mm
152.5 mm 		15.88 mm
15.99 mm
16.24 mm 		20.13 mm
20.26 mm
20.58 mm 		24.74 mm
24.9 mm
25.3 mm 		30.06 mm
30.27 mm
30.75 mm 		51.19 mm
51.55 mm
52.4 mm 		61.05 mm
61.47 mm
62.49 mm 		81.1 mm
81.67 mm
83.02 mm 		101.22 mm
101.93 mm
103.61 mm 		202.75 mm
204.18 mm
207.56 mm 		151.08 mm
152.14 mm
154.66 mm 		30.18 mm
30.39 mm
30.88 mm 		50.42 mm
50.77 mm
51.6 mm 		79.41 mm
79.96 mm
81.28 mm 		100.4 mm
101.1 mm
102.8 mm 		149.6 mm
150.7 mm
153.1 mm 		30.02 mm
30.25 mm
30.75 mm 		41.77 mm
42.06 mm
42.74 mm 		51.62 mm
51.98 mm
52.83 mm 		71.15 mm
71.65 mm
72.82 mm 		130.14 mm
131.06 mm
133.23 mm
Outer Mount Diameter 16.0 mm 25.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 30.0 mm 30.0 mm 30.0 mm 30.0 mm 30.0 mm 35.0 mm 35.0 mm 35.0 mm 35.0 mm 35.0 mm
Part Number G052201000 G063023000 G052202000 G052203000 G052204000 G052205000 G052206000 G052207000 G052208000 G052211000 G063033000 G063020000 G063021000 G063022000 G063024000 G063025000 G063026000 G063027000 G063029000 G063028000 G063851000 G063852000 G063853000 G063854000 G063855000 G063151000 G063012000 G063013000 G063014000 G063155000

  • Two equal radii of curvature for precision 1:1 imaging

  • Tight manufacturing tolerances for excellent performance and precision mounting

  • Uncoated lens suitable for broad wavelength range

  • Mount made of black anodized aluminum with laser engraving

  • ZEMAX files available, enabling easy system design and simulation

ZEMAX-Files Symmetric-Convex Lenses
Product Biconvex lens; N-BaK 4; D=6; F=5; mounted Biconvex lens; N-BK 7; D=22.4; F=40; mounted Biconvex lens; N-BaK 4; D=8; F=7; mounted Biconvex lens; N-BaK 4; D=10; F=10; mounted Biconvex lens; N-BK 7; D=12.5; F=12.5; mounted Biconvex lens; N-BK 7; D=12.7; F=15; mounted Biconvex lens; N-BK 7; D=12.7; F=20; mounted Biconvex lens; N-BK 7; D=12.7; F=30; mounted Biconvex lens; N-BK 7; D=12.7; F=50; mounted Biconvex lens; N-BK 7; D=12.7; F=150; mounted Biconvex lens; N-BK 7; D=18; F=16; mounted Biconvex lens; N-BK 7; D=22.4; F=20; mounted Biconvex lens; N-BK 7; D=22.4; F=25; mounted Biconvex lens; N-BK 7; D=22.4; F=30; mounted Biconvex lens; N-BK 7; D=22.4; F=50; mounted Biconvex lens; N-BK 7; D=22.4; F=60; mounted Biconvex lens; N-BK 7; D=22.4; F=80; mounted Biconvex lens; N-BK 7; D=22.4; F=100; mounted Biconvex lens; N-BK 7; D=22.4; F=200; mounted Biconvex lens; N-BK 7; D=22.4; F=150; mounted Biconvex lens; N-BK 7; D=25.4; F=30; mounted Biconvex lens; N-BK 7; D=25.4; F=50; mounted Biconvex lens; N-BK 7; D=25.4; F=80; mounted Biconvex lens; N-BK 7; D=25.4; F=100; mounted Biconvex lens; N-BK 7; D=25.4; F=150; mounted Biconvex lens; N-SK2; D=31.5; F=30; mounted Biconvex lens; N-BK 7; D=31.5; F=40; mounted Biconvex lens; N-BK 7; D=31.5; F=50; mounted Biconvexl lens; N-BK 7; D=31.5; F=70; mounted Biconvex lens; N-BK 7; D=31.5; F=130; mounted
Shape Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular Circular
Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted Mounted
Mount Nanobench Microbench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Nanobench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench Microbench
Focal Length (+/-) 5.0 mm 40.0 mm 7.0 mm 10.0 mm 12.5 mm 15.0 mm 20.0 mm 30.0 mm 50.0 mm 150.0 mm 16.0 mm 20.0 mm 25.0 mm 30.0 mm 50.0 mm 60.0 mm 80.0 mm 100.0 mm 200.0 mm 150.0 mm 30.0 mm 50.0 mm 80.0 mm 100.0 mm 150.0 mm 30.0 mm 40.0 mm 50.0 mm 70.0 mm 130.0 mm
Optic Substrate N-BAK4 N-BK7 N-BAK4 N-BAK4 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-BK7 N-SK2 N-BK7 N-BK7 N-BK7 N-BK7
Optic Size Ø 6.0 mm Ø 22.4 mm Ø 8.0 mm Ø 10.0 mm Ø 12.5 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 12.7 mm Ø 18.0 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 22.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm Ø 31.5 mm
Optic Center Thickness 2.9 mm 5.0 mm 3.4 mm 3.5 mm 4.5 mm 4.0 mm 3.0 mm 3.0 mm 3.0 mm 3.0 mm 7.0 mm 8.8 mm 7.0 mm 6.3 mm 4.5 mm 4.0 mm 3.5 mm 3.5 mm 3.0 mm 3.0 mm 7.0 mm 7.0 mm 7.0 mm 7.0 mm 7.0 mm 9.5 mm 8.3 mm 7.0 mm 5.5 mm 4.0 mm
Length 8.0 mm 10.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 8.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 10.0 mm 12.0 mm 12.0 mm 12.0 mm 12.0 mm 12.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm
Radius of Curvature 1 5.085 mm 41.867 mm 7.499 mm 10.669 mm 11.971 mm 14.749 mm 20.097 mm 30.287 mm 51.08 mm 153.99 mm 15.179 mm 19.248 mm 24.406 mm 30.069 mm 52.33 mm 62.643 mm 83.536 mm 104.41 mm 209.83 mm 156.22 mm 30.069 mm 51.08 mm 81.166 mm 102.92 mm 153.99 mm 34.721 mm 41.867 mm 52.33 mm 72.862 mm 134.325 mm
Radius of Curvature 2 -5.085 mm -41.867 mm -7.499 mm -10.669 mm -11.971 mm -14.749 mm -20.097 mm -30.287 mm -51.08 mm -153.99 mm -15.179 mm -19.248 mm -24.406 mm -30.069 mm -52.33 mm -62.643 mm -83.536 mm -104.41 mm -209.83 mm -156.22 mm -30.069 mm -51.08 mm -81.166 mm -102.92 mm -153.99 mm -34.721 mm -41.867 mm -52.33 mm -72.862 mm -134.325 mm
Tolerance thickness ± 0.1 mm ± 0.2 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.1 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm ± 0.2 mm
Optic Edge Thickness 0.9 mm 2.0 mm 1.1 mm 1.0 mm 1.0 mm 1.1 mm 0.9 mm 1.6 mm 2.2 mm 2.7 mm 1.1 mm 1.6 mm 1.6 mm 2.0 mm 2.1 mm 2.0 mm 2.0 mm 2.3 mm 2.4 mm 2.2 mm 1.4 mm 3.8 mm 5.0 mm 5.4 mm 6.0 mm 2.0 mm 2.1 mm 2.1 mm 2.1 mm 2.2 mm
Optic Centering Accuracy (min,sec) 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 10.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 ' 3.0 '
Tolerance of optic size - 0.075 mm - 0.13 mm - 0.09 mm - 0.09 mm - 0.11 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.12 mm - 0.11 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.13 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.06 mm - 0.07 mm - 0.07 mm - 0.07 mm - 0.07 mm - 0.07 mm
f' at X nm 4.97 mm
5.0 mm
5.08 mm 		41.2 mm
41.48 mm
42.16 mm 		7.14 mm
7.21 mm
7.33 mm 		9.93 mm
10.01 mm
10.17 mm 		12.33 mm
12.41 mm
12.61 mm 		14.91 mm
15.01 mm
15.25 mm 		19.88 mm
20.02 mm
20.34 mm 		29.7 mm
29.9 mm
30.4 mm 		49.74 mm
50.08 mm
50.91 mm 		148.9 mm
150.0 mm
152.5 mm 		15.88 mm
15.99 mm
16.24 mm 		20.13 mm
20.26 mm
20.58 mm 		24.74 mm
24.9 mm
25.3 mm 		30.06 mm
30.27 mm
30.75 mm 		51.19 mm
51.55 mm
52.4 mm 		61.05 mm
61.47 mm
62.49 mm 		81.1 mm
81.67 mm
83.02 mm 		101.22 mm
101.93 mm
103.61 mm 		202.75 mm
204.18 mm
207.56 mm 		151.08 mm
152.14 mm
154.66 mm 		30.18 mm
30.39 mm
30.88 mm 		50.42 mm
50.77 mm
51.6 mm 		79.41 mm
79.96 mm
81.28 mm 		100.4 mm
101.1 mm
102.8 mm 		149.6 mm
150.7 mm
153.1 mm 		30.02 mm
30.25 mm
30.75 mm 		41.77 mm
42.06 mm
42.74 mm 		51.62 mm
51.98 mm
52.83 mm 		71.15 mm
71.65 mm
72.82 mm 		130.14 mm
131.06 mm
133.23 mm
Outer Mount Diameter 16.0 mm 25.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 16.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 25.0 mm 30.0 mm 30.0 mm 30.0 mm 30.0 mm 30.0 mm 35.0 mm 35.0 mm 35.0 mm 35.0 mm 35.0 mm
Part Number G052201000 G063023000 G052202000 G052203000 G052204000 G052205000 G052206000 G052207000 G052208000 G052211000 G063033000 G063020000 G063021000 G063022000 G063024000 G063025000 G063026000 G063027000 G063029000 G063028000 G063851000 G063852000 G063853000 G063854000 G063855000 G063151000 G063012000 G063013000 G063014000 G063155000

  • Two equal radii of curvature for precision 1:1 imaging

  • Tight manufacturing tolerances for excellent performance and precision mounting

  • Uncoated lens suitable for broad wavelength range

  • Mount made of black anodized aluminum with laser engraving

  • ZEMAX files available, enabling easy system design and simulation

ZEMAX-Files Symmetric-Convex Lenses
