PART/ PE1200D-13F
PE1200D-13F Xenon Ceramic Body Elliptical Lamp, 1200W
The 1200 Watt Cermax® Xenon lamp expands on the capabilities of the 1000 Watt lamp, providing an even higher intensity light while still maintaining the broad spectrum, compactness and high robustness associated with Cermax products. Built with an elliptical reflector to provide a short focal distance, the lamp produces high intensity focused light with applications ranging from wafer inspection and machine vision to solar simulation and spotlights or beacons.
The PE1200D-13F features high-intensity illumination - 30,000 Lumens, with a power range of 950-1250 Watts. It has a broad spectral range with 5,900 Kelvin color temperature, and a lamp lifetime of 1,000 hours.
| Reflector Type | Elliptical, f/1.3 |
| Body Type | Ceramic |
| Total Visible Output | 30,000 Lumens |
| Power - Nominal | 1200 Watts |
| Power - Range | 950-1250 Watts |
| Current | Nominal: 63 Amps (DC) |
| Current - Range | 45-70 Amps (DC) |
| Ignition Voltage | 28 kilovolts (recommended minimum, system dependent) |
| Operating Voltage - Nominal | 19 Volts (DC) |
| Operating Voltage - Range | 17-22 Volts (DC) |
| Lifetime | 1000 hours typical |
| Temperature | 150° C (maximum) |
| Radiant Output | 273 Watts |
| UV Output (<390 nm) | 14.6 Watts |
| IR Output (>770 nm) | 150 Watts |
