PART/ PE300C-10F
PE300C-10F Xenon Ceramic Body Elliptical Lamp, 300W
The integrated elliptical reflector in this 300 Watt Cermax® Xenon lamp creates a converging beam eliminating the need for secondary focusing optics. The unique oversized reflector improves light collection and maximizes the efficiency of the lamp. This lamp is well suited for use where small aperture sizes are a requirement.
The PE300C-10F features high-intensity, focused illumination - 7475 Lumens, with a power range of 200-300 Watts. It has a broad spectral range with 5900 Kelvin color temperature, and a lamp lifetime of 1,000 hours.
| Reflector Type | Elliptical, f/1.0 |
| Body Type | Ceramic |
| Total Visible Output | 7475 Lumens |
| Power - Nominal | 300 Watts |
| Power - Range | 200-300 Watts |
| Current - Nominal | 21 Amps (DC) |
| Current - Range | 13-26.5 Amps (DC) |
| Ignition Voltage | 23 kilovolts (recommended minimum, system dependent) |
| Operating Voltage - Nominal | 12 Volts (DC) |
| Operating Voltage - Range | 11.5-15 Volts (DC) |
| Lifetime | 1000 hours typical |
| Temperature | 150° C (maximum) |
| Radiant Output | 75 Watts |
| UV Output (<390 nm) | 3.8 Watts |
| IR Output (>770 nm) | 37 Watts |
| Reflector Type | Elliptical, f/1.0 |
| Body Type | Ceramic |
| Total Visible Output | 7475 Lumens |
| Power - Nominal | 300 Watts |
| Power - Range | 200-300 Watts |
| Current - Nominal | 21 Amps (DC) |
| Current - Range | 13-26.5 Amps (DC) |
| Ignition Voltage | 23 kilovolts (recommended minimum, system dependent) |
| Operating Voltage - Nominal | 12 Volts (DC) |
| Operating Voltage - Range | 11.5-15 Volts (DC) |
| Lifetime | 1000 hours typical |
| Temperature | 150° C (maximum) |
| Radiant Output | 75 Watts |
| UV Output (<390 nm) | 3.8 Watts |
| IR Output (>770 nm) | 37 Watts |
