PART/ C30703FH-200
C30703FH-200 - Si APD, 10x10mm, Flatpack without Glued Window
The C30703FH-200 Silicon Avalanche Photodiode (Si APD) with dimensions of 10 mm x 10 mm is designed for extremely large areas and offered in a flat pack suitable for radiation detection. The C30703 Si APD is enhanced for blue wavelength response and has a peak quantum efficiency at ~ 530 nm.
Features & Benefits:
- High-quantum efficiency
- Low dark currents
- Easy coupling to scintillator crystals
- Immunity to electromagnetic fields
- Short wavelength enhanced responsivity. Custom packaging available
- Excellent timing resolution
- RoHS compliant
Applications:
- High energy physics
- Radiation detection
- Particle physics
- Instrumentation
- Environmental monitoring
Active Area: 100 mm²
Vop Range: 275 - 425V
Capacitance: 60 pF
Dark Current: 250 nA
Noise Current: 0.7 pA/√Hz
NEP: 40 fW/√Hz, 530nm
Package: Flat-pack
Peak Sensitivity Wavelength: 530nm
Photosensitive area: 10 x 10 mm
Response Time: 5 ns
Responsivity: 16 A/W at 530 nm
